Product Classification
The ZR-X window film series is divided into four core categories according to functions and application scenarios, accurately matching the needs of different users:
- High-end Heat Insulation and Privacy Series: High heat insulation rate + high privacy, specially designed for car owners pursuing comfort and privacy
- High-Definition Light Transmission Series: High light transmittance + low reflection, suitable for front windshields and scenarios requiring high visibility
- New Energy Special Series: Signal compatibility + high-efficiency heat insulation, does not block 5G, ETC, navigation signals, suitable for new energy vehicles
- Economical and Practical Series: Basic heat insulation + UV protection, a cost-effective choice to meet daily protection needs

Product Description
ZR-X window film is a high-performance automotive window film produced with imported Korean equipment. Based on multi-layer polyester film as the base material, it integrates advanced technologies such as nano-ceramics and metal sputtering, and has multiple functions including heat insulation, UV protection, privacy protection, and safety explosion-proof. The product can effectively block more than 99% of ultraviolet rays, reducing skin sunburn and interior aging; block 50%-80% of infrared heat, lower the temperature inside the car, and reduce air conditioning energy consumption; at the same time, it has a certain explosion-proof performance, which can adhere to fragments when the glass breaks, avoiding personal injury. Different series of products are optimally designed for different needs, creating a comfortable, safe and private in-car environment for car owners.

Features & Advantages
- High-Efficiency Heat Insulation: Blocks 50%-80% of infrared heat, can reduce the temperature inside the car by 5-10℃ in summer, improve riding comfort, and save fuel/electricity consumption
- Comprehensive UV Protection: UV blocking rate ≥ 99%, effectively protecting the skin of drivers and passengers, delaying interior aging and fading
- High-Definition Vision: Uses high-definition base material, no fog, no rainbow pattern, and does not affect the clarity of vision at night and in rainy days
- Signal Compatibility: The new energy special series has passed signal compatibility certification and does not block 5G, ETC, navigation signals
- Safety Explosion-Proof: Can adhere to fragments when the glass breaks, preventing secondary damage caused by fragment splashing
- Long-Term Warranty: 3-10 years of warranty (varies by series). If bubbles, fading, or attenuation of heat insulation effect occur during the warranty period, free rework or replacement is provided
- Easy to Clean: The surface has an anti-fouling coating, stains are easy to wipe, and scale is not easy to remain
Product Introduction
The ZR-X window film series relies on imported Korean production technology and strictly implements full-cycle quality control of "raw material - production - factory delivery" to ensure stable product quality. The product uses imported polyester film as the base material and is made through multiple processes such as multi-layer compounding, coating curing, and precision cutting; it additionally conducts dual-index testing of "light transmittance + heat insulation rate", complying with national standard GB/T 2680-2021 and international standards such as European CE certification, EU RoHS certification, and SGS certification. Whether it is luxury car owners pursuing ultimate heat insulation, ordinary car owners focusing on cost-effectiveness, or the special needs of new energy car owners, you can find suitable products in the ZR-X window film series to comprehensively improve the riding experience.
Product Specifications
|
Product Series |
Thickness |
Width |
Length |
Applicable Parts |
|
Premium Heat Insulation & Privacy Series |
2mil,4mil |
1.52m |
30m/roll |
Side Windows, Rear Windshield |
|
High-Definition Light-Transmitting Series |
2mil,4mil |
1.52m |
30m/roll |
Front Windshield, Side Windows |
|
New Energy Vehicle-Specific Series |
2.0mil |
1.52m |
30m/roll |
Full Vehicle Glass |
|
Economical & Practical Series |
1.8mil |
1.52m |
30m/roll |
Full Vehicle Glass |
Technical Parameters
|
Test Items |
High-end Heat Insulation and Privacy Series |
High-Definition Light Transmission Series |
New Energy Special Series |
Economical and Practical Series |
|
Infrared Blocking Rate |
≥97% |
≥88% |
≥75% |
≥50% |
|
UV Blocking Rate |
≥99% |
≥99% |
≥99% |
≥99% |
|
Visible Light Transmittance |
15%-35% |
≥70% |
35%-70% |
35%-50% |
|
Visible Light Reflectance |
≤10% |
≤8% |
≤9% |
≤12% |
|
Explosion-Proof Performance |
Can withstand 5kg steel ball falling impact from 1.5m |
Can withstand 5kg steel ball falling impact from 1.2m |
Can withstand 5kg steel ball falling impact from 1.5m |
Can withstand 5kg steel ball falling impact from 1.0m |
Material
- Core Substrate: Multi-layer imported polyester film, with excellent light transmittance, toughness and weather resistance;
- Functional Coating: High-end series adopts nano-ceramic coating/metal sputtering coating, with high-efficiency heat insulation and signal compatibility; Basic series adopts dyeing + vacuum aluminized coating, balancing heat insulation and cost-effectiveness;
- Adhesive: Special environmentally friendly acrylic adhesive, stable viscosity, firm adhesion, no residual adhesive after removal;
- Surface Protection Layer: Scratch-resistant coating, improving film wear resistance, not easy to produce scratches.
Appearance
- The film surface is flat and smooth, no impurities, no bubbles, no rainbow patterns;
- Color options: Privacy black, dark gray, light gray, natural color, etc.;
- Clear vision after fitting the glass, no fog, no impact on driving vision;
- The edges are cut neatly, perfectly fit the glass after construction, no obvious seams.
Design
- Adopts ultra-thin design, does not affect the glass lifting function, does not increase the glass weight;
- Optimizes flexibility for different glass curves to ensure construction fit;
- Edge micro-shrinking design reduces the risk of edge warping;
- Adhesive micro-grid design facilitates air exhaust and bubble removal during construction, improving construction efficiency;
- Supports customized color design, such as dream gradient, privacy black, etc., to meet personalized needs.
